- to be used with (code)
- OP906, OP913, OP914, OP923
- Type
- LED
- Product Search Type
- Light Source
- Discipline
- General / Visceral Surgery, Arthroscopy, Urology
- System
- LED
- Type of Sterilization
- not to be sterilized
- Product contains Latex
- No
- Indication
- Laparoscopy, Hysteroscopy
- Integrated spare lamp
- No
- Aesculap Product Groups
- Endoscopic Technology
- Sterility
- non-sterile
- Safety class acc to EN 60601-1
- I
- Lamp intensity increase
- continuously
- Tested acc to norm
- EN 60601-1-2, EN 60601-1
- Protection level acc EN_606011
- CF
- Disposable / Reusable
- reusable
- Power supply
- 100-240 V AC, 50/60Hz
- Product family
- Equipment
- Height
- 146 MM
- Depth (mm)
- 362 MM
- Weight
- 8500 G
- Maximum power consumption
- 625 VA
- Width (mm)
- 330 MM
